- FACIAL FUNCTION: 1 CHANNEL FACIAL RECOGNITION
- WEB FUNCTION: MULTI BROWSER SUPPORT: CHROME, FIREFOX, SAFARI. REAL REMOTE MONITORING AND PLAYBACK.
- OPERATION SYSTEM: EMBEDDED LINUX
- PENTAPLEX FUNCTION: LIVE MONITORING, RECORDING, PLAYBACK, BACKUP & REMOTE ACCESS
- CONTROL MODE: USB MOUSE, NETWORK
- INPUT:8 CHANNEL BNC
- STANDARD: PAL (625LINE, 50F/S) NTSC (525LINE, 60F/S)
- OUTPUT: 1 CVBS, BNC (1.0VP-P,75 OHMS) 1 HDMI, 1.3A,SUPPORT 1920×1080 RESOLUTION 1 VGA,1920×1080,1280×1024,1280×720,1024×768,800×600 RESOLUTION
- INPUT: 4 CH BNC
- OUTPUT: 1 BNC
- TWO-WAY AUDIO: YES
- RESOLUTION: PAL, 960H(960×576),D1(704× 576 / NTSC,960H(960×480), D1 (720×480)
- TOUR DISPLAY: YES
- PRIVACY MASKING: FOUR ZONES FOR PRIVACY MASKING FOR EACH CHANNEL
- VIDEO COMPRESSION: H.264
- AUDIO COMPRESSION: G.711A
- IMAGE ENCODING: ADJUSTABLE ENCODING QUALITY, VARIABLE CODE STREAM/FIXED CODE STREAM
- DUAL STREAM: YES
- RECORDING RESOLUTION: 4 CHANNEL, 960H/D1
- 960H: 8 CHANNEL 960H/D1 REALTIME, 8 CHANNEL 960H RECORDING, 4 CHANNEL PLAYBACK
- RECORDING MODE: MANUAL, AUTO, MOTION DETECTION
- TIME BAR: YES
- TRIGGER EVENTS: RECORDING, TOUR,EMAIL
- PLAYBACK CHANNEL: 1/2/4/8 CHANNEL
- BACKUP MODE: USB, HDD, NETWORK BACKUP
- ETHERNET: 1 RJ-45 PORT (10M/100M)
- NETWORK PROTOCOL: TCP/IP, UDP, HTTP, RTP/RTSP
- NETWORK FUNCTIONS: DHCP, PPPOE, DDNS, SMTP, SNTP ,FTP, UPNP
- REMOTE OPERATION: MONITORING, PTZ CONTROL, PLAYBACK, SYSTEM SETTING, FILE DOWNLOAD, LOG INFORMATION
- SMART PHONE: IPHONE, IPAD, ANDROID, BLACKBERRY, WINDOWS MOBILE
- HARD DISK: 2 SATA PORT UP TO 2 X 4TB HDD
- HDD MANAGEMENT: HARD DISK HIBERNATION TECHNOLOGY AND HDD ALARM
- USB INTERFACE: 2 USB 2.0 PORTS
- POWER SUPPLY: DC12V/2A
- POWER CONSUMPTION: 20W (WITHOUT HDD)
- WORKING ENVIRONMENT: -10-55 degree
- DIMENSION( WXDXH): 1U, 360x250x48MM(WXDXH)
- WEIGHT: 2.0KG (WITHOUT HDD)
- INSTALLATION: DESK TYPE
Other Features
- 8 channels D1/960H real time recording
- H.264 Compression
- VGA/HDMI output
- 1 Channel with facial detection
- Simultaneous playback of all channels
- Archiving to USB
- Remote Connection via Web Bowser or Smart Phone
