Designed to fit neatly under an overhead unit or cabinet this canopy cooker hood is a discreet and effective extractor that will clear your kitchen without taking up valuable space.
Reduced Noise
The low-noise motor provides powerful extraction with reduced noise.
LED Lights
The energy-saving lighting provides bright and clear lighting for the hob area.
Key Features
- Suitable for ducted extraction and recirculation
- Energy Efficiency Class: D
- Max. extraction rate: 302m³/h
- Maximum Noise Level: 62dB
- 3 power levels
- 2 x 3W LED
- 2 year warranty for peace of mind
- Dimensions (mm): H208 x W534 x D300
Design
- Integrated canopy hood
- Mechanical slide controls
- Washable aluminium grease filter
Performance/technical information
- Power rating: 121 W
- Total power of the motors: 115 W
- Total power of the lamps: 6 W
- Light Intensity: 78 lux
- Electrical cable length 1.5 m
- Diameter pipe Ø 120 mm (Ø 120 mm enclosed)
- Dimensions exhaust air (HxWxD): 208-208 x 534 x 300 mm
- Dimensions recirculating (HxWxD): 208-208 x 534 x 300 mm
- Mounting dimensions: width: 49 cm, depth: 26 cm
- Blower Efficiency Class: E
- Lighting Efficiency Class: D
- Grease Filtering Efficiency Class: D
- Average Energy Consumption: 67.7 kWh/year
Optional accessories
- Recirculating kit DWZ0IN0A0
Question from Sheila Hill: Asked on 25/09/2025 Will the Bosch 2 54cm canopy cooker hood support a 5m duvting pipe ?
Hi Sheila,The Bosch DLN53AA70B canopy cooker hood requires a 120 mm ducting diameter for external extraction, but no maximum length is specified. For optimal performance, however, the ducting should be kept as short and straight as possible; if a 5-metre run is necessary, use smooth-walled ducting and minimize bends to maintain efficiency.Thanks!
Question from Marilyn: Asked on 21/09/2025 Do I need a filter with this extractor? It didn't come with one. Part of a fitted kitchen
Hi Marilyn,The Bosch DLN53AA70B canopy hood includes a washable aluminium grease filter; a separate charcoal filter is only required for odour removal when the unit is set to recirculation mode, but is not needed if the hood is ducted to vent air outside.Thanks!
