The Details
The electriQ RF Smart Thermostat offers a simple and convenient way to control your heating system, helping you maintain a comfortable temperature while managing your heating more efficiently.
Featuring reliable 433.92MHz RF communication, the thermostat communicates wirelessly with the receiver over distances of up to 200 metres in open areas and up to 50 metres indoors. This gives you greater flexibility over where the thermostat is positioned, without requiring control wiring between the thermostat and boiler.
Connect the system to the Smart Life app to monitor and adjust your heating remotely from your smartphone. Compatibility with Amazon Alexa and Google Home also allows convenient voice control using supported commands.
Designed for modern homes, the thermostat features flexible weekly programming, frost protection, child lock, low battery alerts and adjustable temperature settings, giving you greater control over your heating throughout the year.
Key Features
Smart Heating Control from Anywhere:
Connect to the Smart Life app to monitor and adjust your heating remotely from your smartphone, whether you're at home or away.
Long-Range Wireless RF Communication:
The thermostat communicates wirelessly with the receiver using a reliable 433.92MHz RF connection, with a range of up to 200m in open areas and up to 50m indoors, depending on building layout and interference.
Voice Assistant Compatibility:
Works with Amazon Alexa and Google Home, allowing you to control temperature and access supported heating functions using simple voice commands.
Flexible Power Options:
Power the thermostat using three AA batteries, USB Type-C power, or both simultaneously for added reliability.
Flexible Weekly Programming:
Set heating programmes to suit your routine, with 5+2, 6+1 or 7-day programming modes and multiple time and temperature settings.
Adjustable Temperature Control:
Set your preferred temperature between 5°C and 95°C, with adjustable temperature calibration, upper and lower temperature limits and temperature hysteresis settings.
Safety and Convenience Features:
Includes frost protection, child lock, low battery alerts and temperature calibration for convenient everyday use.
Specifications
- Model: RFST-W
- Product Type: RF Smart Thermostat for Wall-Hung Boilers
- Smart App: Smart Life
- Voice Control: Amazon Alexa and Google Home
- Thermostat Power Supply: 3 x AA (LR6) alkaline batteries and/or USB Type-C
- Receiver Power Supply: AC 100-240V, 50/60Hz
- Wireless Frequency: 433.92MHz (FSK)
- RF Range: Up to 200m in open areas / 50m indoors
- Wi-Fi Standard: IEEE 802.11 b/g/n (2.4GHz)
- Wi-Fi Connection Range: Up to 100m in open areas / 30m indoors
- Temperature Setting Range: 5°C - 95°C
- Temperature Calibration: -9.9°C to +9.9°C
- Temperature Hysteresis: 0.1°C - 10°C; 0.5°C default
- Operating Temperature: -5°C to 50°C
- Protection Rating: IP20
- Weekly Programming: Yes
- Frost Protection: Yes
- Child Lock: Yes
- Low Battery Alert: Yes
- Compliance: EU Radio Equipment Directive 2014/53/EU, UK Radio Equipment Regulations 2017 and PSTI
- Warranty: 2 Years
Dimensions
Thermostat
- 86 x 86 x 30.8 mm
Receiver
- 86 x 86 x 26 mm
Notes
- Suitable for compatible wall-hung boiler heating systems. Check boiler compatibility before installation.
- Installation must be carried out by a qualified electrician in accordance with applicable wiring regulations.
- The thermostat and receiver must be paired before use.
- A 2.4GHz Wi-Fi network is required for Smart Life app connectivity and smart functions.
What is in the box
- 1 x RF Smart Thermostat
- 1 x RF Receiver
- 1 x Thermostat Mounting Bracket
- 1 x USB Type-C Cable
- 1 x Screw Pack
- 1 x User Manual
