Smeg SPD505SUK Ecoline Front Loading Undercounter Dishwasher with Water Softener & Drain Pump - 500mm Basket
Key Features
- High-Volume Throughput: Delivers a commercial output of up to 40 baskets per hour, processing 720 plates or 1,000 pint glasses per hour.
- Flexible Power Configuration: 6.8kW total loading with multi-phase electrics, allowing for professional installation on 13A, 20A, or 32A single-phase supplies.
- Enhanced Thermal Efficiency: Features a double-skinned insulated door and a moulded tank with radius corners to reduce heat loss, noise, and soil build-up.
- Integrated Water Treatment: Built-in water softener ensures consistent results in hard water areas and protects internal components from limescale.
- Commercial Warranty: Provided with a two-year manufacturer on-site parts and labour warranty for operational security.
The Smeg SPD505SUK is a high-performance undercounter solution designed for bars, cafes, and restaurants requiring consistent hygiene and rapid turnaround. Utilizing a standard 500mm basket, this unit achieves a throughput of up to 40 baskets per hour, equivalent to 720 plates or 1,000 pint glasses, making it ideal for medium-footfall venues. The 340mm usable loading height accommodates large dinner plates and tall glassware, while the Soft Start system gradually increases pump pressure to protect fragile crystal and ceramic items from damage.
This Italian-engineered unit features a 6.8kW total loading and is supplied for 30A single-phase hardwired connection as standard. The multi-phase electrics provide installation flexibility, permitting a qualified engineer to configure the unit for 13A, 20A, or 32A supplies depending on site requirements. To guarantee sanitisation, the HTR (High Temperature Rinse) system employs an atmospheric boiler to maintain a constant 85-87°C rinse temperature. The dishwasher is fully compliant with WRAS regulations, featuring a KIWA-approved internal break tank and rinse booster pump for consistent performance even with fluctuating water pressure between 1 and 10 bar.
Operational efficiency is enhanced by three selectable wash programmes (90, 150, and 240 seconds) and an intuitive electronic control panel with a self-diagnosis system. Maintenance is streamlined through a patented four-stage filtration system that protects the wash and drain pumps from food debris, alongside removable stainless steel wash arms and an automatic self-cleaning cycle. The unit is supplied ready for commission with integrated rinse aid and detergent dosing pumps, a drain pump, one open basket, one pegged plate basket, and one cutlery basket.
