Browse the collections
The details
Elevate the look and comfort of your home with our Riace range of stylish Vertical designer radiators. Perfectly suited for traditional and modern interiors, these radiators combine sleek design with high-performance heating. The slim, vertical form fits seamlessly into any room, from living areas to bedrooms, while offering powerful and efficient heating.
Riace vertical designer radiators are engineered to provide maximum heating output, ensuring your space is always warm and inviting, even in the coldest months. Available in single and double-panel options, they are designed to meet various heating needs. Whether you're looking for a space-saving radiator for a compact room or a more powerful unit for a larger space, you’ll find the perfect match with Riace’s diverse range of space-saving sizes and styles.
Constructed from premium steel, these radiators are built for durability and long-lasting performance. Each radiator is finished with a resilient coating that guards against wear and tear, ensuring easy maintenance while adding a contemporary touch to your décor. Designed for central heating systems, Riace radiators ensure consistent and reliable warmth throughout your home.
Key features
- Sleek vertical double-panel radiator with 8 flat bars, perfect for both modern and classic interiors
- Double panel flat tubes for enhanced thermal efficiency
- 3535 BTU / 2778 BTU (Delta T60 / T50) heat output
- Full range available in a variety of single and double-panel options
- Durable construction with a high-quality finish for long-lasting use
- Easy to maintain – can be cleaned repeatedly without affecting quality or finish
- Powder-coated steel – resistant to scratches, stains, impacts, chemicals, acids, and UV-resistant
- A variety of sizes and colours to fit different designs and layouts
- Compatible with all central heating systems
- Approx. Wall to Radiator Face (mm): 93 mm
- Approx. Wall to Pipe Centre: 63 mm
- Approx. Pipe Centre to Pipe Centre: 352 mm
- Built to Last: 1.5mm thick steel for guaranteed durability
- Tested and certified by a notified body to CE/ BS EN 442 Standards
- CE Marked and Declaration of Performance provided (DOP)
- ISO 9001:2015 / GB/T19001-2016 Registered Manufacturer
- Includes User Manual, Wall fixings, Wall plugs, Blanking and Bleed plug
Specifications
- Wall Mounted: Yes
- Colour: White RAL: 9016
- Net Size (HxWxD): 180x27.2x6.1 cm
- Gross Size (HxWxD): 187x34.2x10.1 cm
- Net Weight: 21.6 kg
- Gross Weight: 23.1 kg
- Panel Type: Double
- Columns per panel: 4
- Shape: Flat
- Direction: Vertical
- Max Operation Pressure: 4 bar
- Max Operation Temperature: <95°C
- Connection Size: ½ inch BSP
- Water Content: 7.53 litres
Please note: Valves are not included but can be added to your order separately (See recommended accessories). All measurements are approximate. We recommend purchasing radiators and valves before fitting the pipework.
Choose this White Vertical Flat Double-panel superior performance radiator from the Riace range to give your house an up-to-date look while making the most of your space.
Downloads
User manualDeclaration of Performance (DOP)
Question from Sam: Asked on 01/05/2026 is the depth from the wall inclusive of the radiator? or will it be 93mm off the wall plus then the 70mm depth of rad? thanks!
Hi, The 93mm measurement is the total distance from the finished wall to the front of the radiator once installed. It already includes the radiator body depth, brackets, and required wall clearance, so it is not an additional figure on top of the radiator’s thickness. You should not add the radiator depth separately, as this has already been accounted for in the stated projection.
Thank you.
Question from Riace designer vertical rad: Asked on 16/01/2025 Hi can you give me the pipe centres distance ,on the 280 mmx 1800 mm double radiator..
Many thanks Richard whiston
please on the 280 mm x
Hi Richard,
Thanks for getting in touch
Approx. Wall to Pipe Centre: 63 mm
Approx. Pipe Centre to Pipe Centre: 372 mm
Hope this helps,
Sam
